Zebra TC56 Integrator Guide

A - 2 TC56 Touch Computer Integrator Guide for Android Version 6.0.1
Performance Characteristics
CPU Snapdragon 650 64-bit Hex Core 1.8GHz ARM Cortex A72, power
optimization
Operating System Android 6.0.1 Marshmallow with Zebra’s Mobility Extensions (Mx)
(pre-installed on both AOSP and GMS options)
Memory Standard: 2 GB RAM/16 GB Flash
Optional: 4 GB RAM/32 GB Flash
Output Power USB - 5 VDC @ 500 mA max
User Environment
Operating Temperature -10°C to 50°C (14°F to 122°F)
Storage Temperature -40°C to 70°C (-40°F to 158°F)
Charging Temperature 0° C to 40° C (32°F to 104°F)
Relative Humidity Operating: 5 to 95% non-condensing
Drop Specification Multiple 1.2 m (4 ft.) to tile over concrete over operating temperature range.
Multiple 1.5 m (5 ft.) to concrete with Rugged Boot over operating temperature
range.
Tumble 500 0.5 m (1.6 ft.) tumbles; meets and exceeds IEC tumble specifications
Electrostatic Discharge (ESD) +/-15 kVDC air discharge, +/-10 kVDC direct discharge, +/- 10 kVDC indirect
discharge
Vibration 4 g’s PK Sine (5 Hz to 2 kHz); 0.04g2/Hz Random (20 Hz to 2 kHz); 60 minute
duration per axis, 3 axis
Thermal Shock -40°C to 70°C (-40°F to 158°F) rapid transition
Interactive Sensor Technology (IST)
Motion Sensor 3-axis accelerometer Gyro; 3-axis accelerometer
Light Sensor Ambient light sensor to auto adjust display backlight brightness
Proximity Sensor Automatically detects when the user places the handset against head during a
phone call to disable display output and touch input.
Table A-1 TC56 Technical Specifications (Continued)
Item Description

Zebra TC56 Specifications

General

Display diagonal	5 \
Touch technology	Dual-touch
Touchscreen type	Capacitive
Display resolution	1280 x 720 pixels
Flash memory	0.016 GB
Internal memory	0.002 GB
Internal memory type	RAM
Compatible memory cards	MicroSD (TransFlash), MicroSDHC
Maximum memory card size	128 GB
Processor family	Qualcomm
Processor frequency	1.8 GHz
Operating system version	6.0
Operating system installed	Android
RFID reader	-
Certification	WFA (802.11n, 802.11ac, WMM-AC, Voice Enterprise, WMM-PS), Miracast WFA (Mobile AP / Personal Hotspot)
Product color	Black, Silver
Linear (1D) barcodes supported	Code 39
International Protection (IP) code	IP67
Battery capacity	4300 mAh
Data network	CDMA, EDGE, GPRS, GSM, HSPA, HSPA+, LTE, UMTS
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.1
GSM bands supported	850, 900, 1800, 1900 MHz
Security algorithms	AES, EAP-TTLS, FIPS 140-2, LEAP, MSCHAPv2, PEAP, TKIP, WEP, WPA, WPA2, WPA2-Enterprise
WCDMA bands supported	850, 1900 MHz
Second camera	No
Rear camera resolution (numeric)	13 MP
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Depth	155 mm
Width	75.5 mm
Height	18.6 mm
Weight	249 g
