Zebra TC56 Integrator Guide

Technical Specifications A - 3
Wireless WAN Data and Voice Communications
Frequency band Worldwide:
LTE: 700,800/900/1800/2100/2600 (FDD 28, 20, 8, 3, 1, 7);
UMTS/HSPA/HSPA+: 850/900/AWS/1900/2100;
GSM/GPRS/EDGE: 850/900/1800/1900
Americas:
LTE: 700/850/1900/AWS (FDD 13,12,17, 5, 2, 4);
UMTS/HSPA/HSPA+: 850, 900, AWS, 1900, 2100;
GSM/GPRS/EDGE: 850/900/1800/1900;
CDMA: 850,1900 (BC0, BC1)
GPS Integrated, Autonomous, Assisted GPS (A-GPS), Navstar, GLONASS,
Beidou, Galileo
Wireless LAN Data and Voice Communications
Radio IEEE 802.11 a/b/g/n/ac/d/h/i/r; Wi-Fi™ certified; IPv4, IPv6
Data Rates Supported 5GHz: 802.11a/n/ac - up to 433.3 Mbps
2.4GHz: 802.11b/g/n - up to 72.2 Mbps
Operating Channels Chan 1 - 13 (2412 - 2472 MHz)
Chan 36 - 165 (5180 - 5825 MHz)
Channel Bandwidth: 20, 40, 80 MHz– Rest of the World
Actual operating channels/frequencies depend on regulatory rules and
certification agency
Security and Encryption WEP (40 or 104 bit); WPA/WPA2 Personal (TKIP, and AES); WPA/WPA2
Enterprise (TKIP and AES) — EAP-TTLS (PAP, MSCHAP, MSCHAPv2),
EAP-TLS, PEAPv0-MSCHAPv2, PEAPv1-EAP-GTC3, EAP Fast3 and LEAP
Certifications WFA (802.11n, WMM-PS)
Fast Roam PMKID caching; Cisco CCKM; 802.11r; OKC
Wireless PAN Data and Voice Communications
Bluetooth Class 2, Bluetooth v4.1 (Bluetooth Smart technology); Bluetooth Wideband
support HFPv1.6; Bluetooth v4.1 Low Energy (LE)
Data Capture Specifications
2D Imager SE4710 imager (1D and 2D) with LED aimer.
Camera Rear — 13 MP autofocus; f/2.4 aperture; rear camera flash LED generates
balanced white light; supports Torch mode.
Near Field Communications (NFC) ISO 14443 Type A and B; F; FeliCa and ISO 15693 cards; P2P mode and
Card Emulation via UICC and Host
Table A-1 TC56 Technical Specifications (Continued)
Item Description

Zebra TC56 Specifications

General

Display diagonal	5 \
Touch technology	Dual-touch
Touchscreen type	Capacitive
Display resolution	1280 x 720 pixels
Flash memory	0.016 GB
Internal memory	0.002 GB
Internal memory type	RAM
Compatible memory cards	MicroSD (TransFlash), MicroSDHC
Maximum memory card size	128 GB
Processor family	Qualcomm
Processor frequency	1.8 GHz
Operating system version	6.0
Operating system installed	Android
RFID reader	-
Certification	WFA (802.11n, 802.11ac, WMM-AC, Voice Enterprise, WMM-PS), Miracast WFA (Mobile AP / Personal Hotspot)
Product color	Black, Silver
Linear (1D) barcodes supported	Code 39
International Protection (IP) code	IP67
Battery capacity	4300 mAh
Data network	CDMA, EDGE, GPRS, GSM, HSPA, HSPA+, LTE, UMTS
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.1
GSM bands supported	850, 900, 1800, 1900 MHz
Security algorithms	AES, EAP-TTLS, FIPS 140-2, LEAP, MSCHAPv2, PEAP, TKIP, WEP, WPA, WPA2, WPA2-Enterprise
WCDMA bands supported	850, 1900 MHz
Second camera	No
Rear camera resolution (numeric)	13 MP
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Depth	155 mm
Width	75.5 mm
Height	18.6 mm
Weight	249 g
