Specifications
Media Specifications
128
79695L-001 Rev. A ZM400/ZM600 User Guide 3/27/07
Media Specifications
Media Specifications ZM400 ZM600
Label length Minimum Tear-off 0.5 in. 13 mm 0.5 in. 13 mm
Peel-off 0.5 in. 13 mm 0.5 in. 13 mm
Rewind 0.5 in. 13 mm 0.5 in. 13 mm
Cutter 1 in. 25.4 mm 1.0 in. 25.4 mm
Maximum 200 or
300 dots/in.
39 in. 991 mm 39 in. 991 mm
600 dots/in. 20 in. 508 mm N/A N/A
Label width Minimum 1 in. 25.4 mm 2 in. 51 mm
Maximum Tear/Cutter 4.5 in. 114 mm 7.0 in. 178 mm
Peel/Rewind 4.25 in. 108 mm 6.75 in. 171 mm
Total thickness
(includes liner, if any)
Minimum 0.0023 in. 0.058 mm 0.0023 in. 0.058 mm
Maximum 0.010 in. 0.25 mm 0.010 in. 0.25 mm
Core size 3 in. 76 mm 3 in. 76 mm
Maximum roll diameter 8 in. 203 mm 8 in. 203 mm
Maximum fanfold pack size
(length x width x height)
8.0 in. ×
4.5 in. ×
6.2 in.
203 mm ×
114 mm ×
157 mm
8.0 in. ×
7.0 in. ×
6.2 in.
203 mm ×
178 mm ×
157 mm
Inter-label gap Minimum 0.079 in. 2 mm 0.079 in. 2 mm
Preferred 0.118 in. 3 mm 0.118 in. 3 mm
Maximum 0.157 in. 4 mm 0.157 in. 4 mm
Ticket/tag notch size (width x length) 0.25 in. ×
0.12 in.
6 mm ×
3 mm
0.25 in. ×
0.12 in.
6 mm ×
3mm
Hole diameter 0.125 in. 3 mm 0.125 in. 3 mm
Notch or hole position
(Centered from inner
media edge)
Minimum 0.15 in. 3.8 mm 0.15 in. 3.8
Maximum 2.25 in. 57 mm 3.5 in. 90 mm
Black mark
dimensions
Vertical length 0.98 in. to
0.453 in.
2.5 to
11.5 mm
0.98 in. to
0.453 in.
2.5 to
11.5 mm
Horizontal width > 0.37 in. >
9.5 mm > 0.37 in. > 9.5 mm
Location Within 0.40 in. (1 mm) of inside media edge
Density, in Optical Density Units (ODU) > 1.0 ODU
Maximum media density 0.5 ODU
