Zebra Z Series ZM600 User Manual

11
Introduction
Control Panel
3/27/07 ZM400/ZM600 User Guide 79695L-001 Rev. A
Control Panel Buttons
Table 1 • Control Panel Buttons
Button Function
FEED
Forces the printer to feed one blank label each time the button is pressed.
• Printer not printing: one blank label immediately feeds.
• Printing: one blank label feeds after the current batch of labels is complete.
PAUSE
Starts and stops the printing process.
• Printer not printing: no printing occurs. (Press
PAUSE again to resume printing.)
• Printing: printing stops after the current label is complete.
CANCEL
Cancels print jobs when the printer is paused.
• Printer not printing: the next stored label format does not print.
• Printing: current label completes printing, and the next label format is cancelled.
Press and hold for several seconds to cancel all print jobs in memory.
SETUP/EXIT
Enters and exits the configuration mode.
SELECT
Toggles the function of PLUS (+) and MINUS (–) between the Scroll and Change
Modes.
• Press once to use
PLUS (+) and MINUS (–) to change the values of the selection.
• Press again to use PLUS (+) and MINUS (–) to scroll through the menu items.
PLUS (+)
(scroll mode)
Scrolls to the next selection.
PLUS (+)
(change mode)
• Increases the value.
• Performs the action on the bottom right of the LCD.
MINUS (–)
(scroll mode)
Scrolls to the previous selection.
MINUS (–)
(change mode)
• Decreases the value.
• Moves to the next available digit in a number.
• Performs the action on the bottom left of the LCD.

Zebra Z Series ZM600 Specifications

General

Memory	16 MB SDRAM; 8 MB Flash
Print Method	Thermal transfer and direct thermal
Print Width	4.09 inches (104 mm)
Resolution	203 dpi/8 dots per mm 300 dpi/12 dots per mm (optional)
Connectivity	USB, Serial, Parallel, Ethernet
Media Sensors	Reflective Transmissive
Media Types	die-cut, continuous, thermal, tag
Ribbon Width	2 in./51 mm to 4.33 in./110 mm
Ribbon Length	450 m/1476 ft
Optional Connectivity	ZebraNet 10/100 Print Server
Operating Temperature	40°F to 104°F/5°C to 40°C
Storage Temperature	-40°F to 140°F/-40°C to 60°C
Humidity	20% to 85% non-condensing
Power Requirements	90-265 VAC, 47-63 Hz
