Zebra Z Series ZM600 User Manual

3/27/07 ZM400/ZM600 User Guide 79695L-001 Rev. A
Index
A
adhesive test for ribbon coating, 27
adjustments
left position, 81
media alignment for rewind, 98
print darkness, 62
printhead pressure, 53
tear-off position, 64
agency approvals, 125
auto calibration, 52
B
backfeed setting, 81
bar codes
list available codes, 70
battery disposal, 88
baud setting, 75
before you begin setup, 16
bitmap scaling factor, 83
C
calibration
media and ribbon sensor, 74
setting for head close, 80
setting for media power up, 80
troubleshooting problems, 108
Canadian DOC compliance, iv
CANCEL button
CANCEL self test, 114
description, 11
checklist
before you begin, 16
troubleshooting, 100
cleaning
cutter module, 94
exterior of printer, 89
media compartment and sensors, 93
printhead and platen roller, 90
recommended cleaning schedule, 89
communication interfaces, 19
communications diagnostics test
overview, 120
selecting, 77
communications problems, 109
components of printer, 9
configuration
changing parameters, 61
enter Setup mode, 56
exit Setup mode, 57
software or printer driver, 61
configuration label
printing using CANCEL self test, 114
printing using List Setup command, 71
connect printer to computer or network, 20
connect to power source, 23
contacts, 3
continuous media
described, 26
setting media type, 65

Zebra Z Series ZM600 Specifications

General

Memory	16 MB SDRAM; 8 MB Flash
Print Method	Thermal transfer and direct thermal
Print Width	4.09 inches (104 mm)
Resolution	203 dpi/8 dots per mm 300 dpi/12 dots per mm (optional)
Connectivity	USB, Serial, Parallel, Ethernet
Media Sensors	Reflective Transmissive
Media Types	die-cut, continuous, thermal, tag
Ribbon Width	2 in./51 mm to 4.33 in./110 mm
Ribbon Length	450 m/1476 ft
Optional Connectivity	ZebraNet 10/100 Print Server
Operating Temperature	40°F to 104°F/5°C to 40°C
Storage Temperature	-40°F to 140°F/-40°C to 60°C
Humidity	20% to 85% non-condensing
Power Requirements	90-265 VAC, 47-63 Hz
