Configuration
Control Panel Parameters
70
79695L-001 Rev. A ZM400/ZM600 User Guide 3/27/07
Print Counter Readings
Prints a label that lists the odometer readings for the following:
• the non-resettable counter
• the two user-controlled counters
• the Early Warning for Maintenance counters, which indicate when the
printhead was last cleaned and the printhead life
If the Early Warning for Maintenance feature is disabled, the counters
related to it do not print.
To print a list of the odometer readings:
1. Press SELECT to select the parameter.
2. Press
PLUS (+) to print the odometer readings.
3. Press SELECT to deselect the parameter.
List Fonts
This option prints a label that lists the available fonts in the printer,
including standard printer fonts plus any optional fonts. Fonts may be
stored in RAM or Flash memory.
To print a list of the available fonts:
1. Press SELECT to select the parameter.
2. Press PLUS (+) to select PRINT.
3. Press
SELECT to deselect the parameter.
ZPL and XML only List Bar Codes
This option prints a label that lists the available bar codes in the printer. Bar
codes may be stored in RAM or Flash memory.
To print a list of the available bar codes:
1. Press SELECT to select the parameter.
2. Press
PLUS (+) to select PRINT.
3. Press
SELECT to deselect the parameter.
List Images
This option prints a label that lists the available images stored in the
printer’s RAM, Flash memory, or optional memory card.
To print a list of the available images:
1. Press SELECT to select the parameter.
2. Press
PLUS (+) to select PRINT.
3. Press
SELECT to deselect the parameter.
Table 12 • Printer Parameters (Page 9 of 24)
Parameter
Action/Explanation
To Next Page
