Zebra Z Series ZM600 User Manual

57
Configuration
Setup Mode
3/27/07 ZM400/ZM600 User Guide 79695L-001 Rev. A
Exit Setup Mode
To leave Setup mode, complete these steps:
1. Press SETUP/EXIT.
The LCD displays
SAVE CHANGES.
2. Press PLUS (+) or MINUS (-) to display the save options:
3. Press SETUP/EXIT to select the displayed choice.
When the configuration and calibration sequence is done,
PRINTER READY displays.
LCD Description
PERMANENT
Stores values in the printer even when power is turned off.
TEMPORARY
Saves the changes until power is turned off.
CANCEL
Cancels all changes made since you entered Setup mode,
except for changes made to the darkness and tear-off settings,
which go into effect as soon as they are made.
LOAD DEFAULTS
Restores all parameters other than the network settings back to
the factory defaults. Use care when loading defaults because
you will need to reload all settings that you changed manually.
Note • Loading factory defaults causes the printer to
auto-calibrate.
LOAD LAST SAVE
Loads values from the last permanent save.
DEFAULT NET
Restores the wired and wireless network settings back to
factory defaults.

Zebra Z Series ZM600 Specifications

General

Memory	16 MB SDRAM; 8 MB Flash
Print Method	Thermal transfer and direct thermal
Print Width	4.09 inches (104 mm)
Resolution	203 dpi/8 dots per mm 300 dpi/12 dots per mm (optional)
Connectivity	USB, Serial, Parallel, Ethernet
Media Sensors	Reflective Transmissive
Media Types	die-cut, continuous, thermal, tag
Ribbon Width	2 in./51 mm to 4.33 in./110 mm
Ribbon Length	450 m/1476 ft
Optional Connectivity	ZebraNet 10/100 Print Server
Operating Temperature	40°F to 104°F/5°C to 40°C
Storage Temperature	-40°F to 140°F/-40°C to 60°C
Humidity	20% to 85% non-condensing
Power Requirements	90-265 VAC, 47-63 Hz
