Zebra Z Series ZM600 User Manual

Operations
Load Media
34
79695L-001 Rev. A ZM400/ZM600 User Guide 3/27/07
3. Insert media into the printer. Follow the instructions for roll or fanfold media, as
appropriate.
Roll Media
Fanfold Media
a. Remove and discard any tags or
labels that are dirty or that are held
by adhesives or tape.
a. Flip down the media supply guide.
b. Flip down the media supply guide. b. Feed the media through the rear or
bottom access slot.
Rear Feed
Bottom Feed
c. Place the roll of media on the media
supply hanger. Push the roll as far
back as it will go.
d. Flip up the media supply guide. c. Drape the media over the media
supply hanger.

Zebra Z Series ZM600 Specifications

General

Memory	16 MB SDRAM; 8 MB Flash
Print Method	Thermal transfer and direct thermal
Print Width	4.09 inches (104 mm)
Resolution	203 dpi/8 dots per mm 300 dpi/12 dots per mm (optional)
Connectivity	USB, Serial, Parallel, Ethernet
Media Sensors	Reflective Transmissive
Media Types	die-cut, continuous, thermal, tag
Ribbon Width	2 in./51 mm to 4.33 in./110 mm
Ribbon Length	450 m/1476 ft
Optional Connectivity	ZebraNet 10/100 Print Server
Operating Temperature	40°F to 104°F/5°C to 40°C
Storage Temperature	-40°F to 140°F/-40°C to 60°C
Humidity	20% to 85% non-condensing
Power Requirements	90-265 VAC, 47-63 Hz
