Zebra Z Series ZM600 User Manual

39
Operations
Load Media
3/27/07 ZM400/ZM600 User Guide 79695L-001 Rev. A
b. Loosen the thumbscrew on the
rewind media guide.
b. Push the liner back until it touches
the back plate of the liner take-up
spindle assembly.
c. Slide the rewind media guide all the
way out, and then fold it down.
d. Slide an empty core onto the rewind
spindle.
c. Wrap the liner around the liner
take-up spindle and turn the spindle
counterclockwise to tighten the liner.
Rewind Option (Continued) Liner Take-Up Option (Continued)

Zebra Z Series ZM600 Specifications

General

Memory	16 MB SDRAM; 8 MB Flash
Print Method	Thermal transfer and direct thermal
Print Width	4.09 inches (104 mm)
Resolution	203 dpi/8 dots per mm 300 dpi/12 dots per mm (optional)
Connectivity	USB, Serial, Parallel, Ethernet
Media Sensors	Reflective Transmissive
Media Types	die-cut, continuous, thermal, tag
Ribbon Width	2 in./51 mm to 4.33 in./110 mm
Ribbon Length	450 m/1476 ft
Optional Connectivity	ZebraNet 10/100 Print Server
Operating Temperature	40°F to 104°F/5°C to 40°C
Storage Temperature	-40°F to 140°F/-40°C to 60°C
Humidity	20% to 85% non-condensing
Power Requirements	90-265 VAC, 47-63 Hz
