Zebra Z Series ZM600 User Manual

Configuration
Control Panel Parameters
72
79695L-001 Rev. A ZM400/ZM600 User Guide 3/27/07
ZPL and XML only Format Memory Card
This option erases all previously stored information from the optional
64 MB flash chip on the Wireless Plus option board. This parameter
appears only when a Wireless Plus option board with the flash chip
populated is installed.
Caution • This option completely erases the flash chip.
To format a memory card:
1. Press SELECT to select the parameter.
2. Press
PLUS (+) to select A:.
If your printer is set to require a password, you are prompted to enter
the password.
3. Enter the password. For instructions, see Change Password-Protected
Parameters on page 58.
4. Press the appropriate button again to select the desired card.
The display shows
ARE YOU SURE?.
5. Do you want to continue?
• Press
MINUS (-) to select NO to cancel the request and return to
FORMAT CARD prompt.
• Press PLUS (+) to select YES and begin initialization.
When initialization is complete, the control panel displays
FORMATTING CARD COMPLETED.
Note • Depending on the amount of memory in the memory card,
initialization may take up to 5 minutes to complete.
6. Press
SELECT to deselect the parameter.
Table 12 • Printer Parameters (Page 11 of 24)
Parameter
Action/Explanation

Zebra Z Series ZM600 Specifications

General

Memory	16 MB SDRAM; 8 MB Flash
Print Method	Thermal transfer and direct thermal
Print Width	4.09 inches (104 mm)
Resolution	203 dpi/8 dots per mm 300 dpi/12 dots per mm (optional)
Connectivity	USB, Serial, Parallel, Ethernet
Media Sensors	Reflective Transmissive
Media Types	die-cut, continuous, thermal, tag
Ribbon Width	2 in./51 mm to 4.33 in./110 mm
Ribbon Length	450 m/1476 ft
Optional Connectivity	ZebraNet 10/100 Print Server
Operating Temperature	40°F to 104°F/5°C to 40°C
Storage Temperature	-40°F to 140°F/-40°C to 60°C
Humidity	20% to 85% non-condensing
Power Requirements	90-265 VAC, 47-63 Hz
