10 Functions at a glance
G-30-1529-en OPMI® VISU 160 on S8, S81 & S88 Suspension Systems Issue 5.0
Printed on 09. 10. 2006
Superlux Eye illumination system with additional
integrated halogen illumination (option)
1 Selecting the filter for Superlux Eye illumination page 82
2 Manual activation of the Superlux Eye backup lamp page 82
3 Opening the Superlux Eye lamp module page 74
4 Additional integrated halogen illumination:
- Closed flap: main lamp is on
- Open flap: backup lamp is on
page 84
5 Selecting the filter for additional integrated halogen
illumination
page 84
6 Opening the lamp module of additional integrated
halogen illumination
page 84
7 Manual activation of the halogen backup lamp page 84
8 Superlux Eye illumination:
Red segment is lit - backup lamp is in use
page 84
2345 6 7 81
