66 Description
G-30-1529-en OPMI® VISU 160 on S8, S81 & S88 Suspension Systems Issue 5.0
Printed on 09. 10. 2006
Binocular tubes and eyepieces
You can mount a 180° tiltable tube, an Invertertube or a 45° inclined tube
on the VISU 160 surgical microscope as required (see the following
pages).
180° tiltable tube
1 PD adjustment knob
The correct position has been reached when the two eyepiece images
merge into one. You can read off the interpupillary distance set on the
adjustment knob.
2 180° tiltable tube
3 Eyepiece mount
45° inclined tube
4 45° inclined tube
5 PD adjustment knob
The correct position has been reached when the two eyepiece images
merge into one. You can read off the interpupillary distance set on the
adjustment knob.
6 Eyepiece mount
