Zeiss S8 - VISU 160 Surgical Microscope

8 Functions at a glance
G-30-1529-en OPMI® VISU 160 on S8, S81 & S88 Suspension Systems Issue 5.0
Printed on 09. 10. 2006
VISU 160 surgical microscope
1 Resetting the X-Y coupling and focus to their initial
positions
page 52
2 Tilting the surgical microscope page 148
3 Adjusting the eyecups page 70
4 Setting your prescription page 70
5 Handgrip page 62
6 Display of the magnification factor of the zoom system page 62
7 DeepView button page 64
8 Selecting light stops page 64
9 Setting the 6° illumination page 64
10 Arrows indicating the focusing range page 60
11 Adjusting the interpupillary distance page 66
12 Manual zoom adjustment page 183
13 Connecting the light guide page 132
