144 Preparations
G-30-1529-en OPMI® VISU 160 on S8, S81 & S88 Suspension Systems Issue 5.0
Printed on 09. 10. 2006
Positioning the S8 ceiling mount
1 Working position
2 Parking position
Working position
• Pull the ceiling mount into the working position using the handle (4).
The recommended height is approx. 1750 mm measured from the
handle to the floor.
• When you release the handle (4), the lift arm (3) is locked in the work-
ing position (1).
Parking position
• Press the release key of the magnetic brakes on the surgical micro-
scope. Move the suspension arm (5) to the highest possible position.
• Push the ceiling mount upward into the parking position using the han-
dle (4). The parking position is the highest possible position.
• When you release the handle (4), the lift arm (3) is locked in the park-
ing position (2).
