G-30-1529-en OPMI® VISU 160 on S8, S81 & S88 Suspension Systems Issue 5.0
Printed on 09. 10. 2006
Preparations 123
Preparations
Attaching the equipment 124
Mounting the surgical microscope 124
Mounting the tube, the eyepieces and the objective lens 128
Changing the microscope accessories 130
Connections 132
Connecting the surgical microscope 132
Connecting the S light guide 132
Strain relief device on S88 floor stand 134
Connecting the S88 floor stand 136
Relocating the system 138
Adjusting the supension system 140
Adjusting the balance setting of the suspension arm 140
Adjusting the limit of downward movement 142
Positioning the S8 ceiling mount 144
Settings on the control and display panel 146
Adjusting the suspension system 146
Adjusting the surgical microscope 147
Adjusting the tilt angle 148
Adjusting the microscope tilt to angles greater than 15° 149
