Controls, displays, connections
1 Securing screw
2 X-Y coupling
3 Actuator button
– recenters the X-Y coupling.
– resets the focus to its initial position in the focusing range
Note:
Press this button to start the recentering movement. To stop this
movement, press the button again.
You can also stop the recentering movement by briefly tipping on one
of the direction keys on the foot control panel.
4 Cable and light guide clip
5 Support arm with tilt device
6 Knob
for setting the tilt angle of the surgical microscope;
+ 180° in the direction of the surgeon,
- 180° in the opposite direction.
7 Arrows indicating the focusing range
If the dot is located between the two arrow tips, the focusing system
of the surgical microscope is in its starting position.
When using a wide-angle observation system
With the wide-angle observation system swung out of the beam path, al-
ways position the microscope body in such a way that index dot (1) for the
microscope's focus is in the middle of triangle (2) of the marking (also see
page 27).
1
2
