G-30-1529-en OPMI® VISU 160 on S8, S81 & S88 Suspension Systems Issue 5.0
Printed on 09. 10. 2006
Preparations 149
Adjusting the microscope tilt to angles greater than 15°
• Remove all accessories mounted on the objective lens (e.g. 0° or 8°
assistant's microscope).
• Turn knob (1) until the surgical microscope is in the viewing position
required.
After the viewing angle has been set, the surgical microscope remains in
this position. The gear drive is self-locking.
1
