146 Preparations
G-30-1529-en OPMI® VISU 160 on S8, S81 & S88 Suspension Systems Issue 5.0
Printed on 09. 10. 2006
Settings on the control and display panel
Adjusting the suspension system
• Turn on the suspension system at its power switch.
• Successively select the following functions on the suspension system:
– lamp brightness,
– motor speeds for zoom,
– focus and
– X-Y coupling.
• Set the lamp brightness as follows:
Start with the minimum brightness setting, and gradually increase the
brightness until the necessary and still admissible level has been
reached.
– Xenon: adjustment range: 1 ... 10
• Set the values required for
– motor speeds of the functions zoom,
– focus and
– X-Y coupling.
Motor speed
Adjustment range: 1...10
Level 1 corresponds to the lowest, level 10 to the highest motor speed.
