106 Description
G-30-1529-en OPMIĀ® VISU 160 on S8, S81 & S88 Suspension Systems Issue 5.0
Printed on 09. 10. 2006
Power switch with connector (option)
The power switch and the connector can be either installed in the OR, or
they can be integrated in the ceiling mount, at the back of the carrier arm
(see illustration).
1 Rail
The delivery package contains a cable clip which is used to guide the
cable of the foot control panel away from the operating table. The
cable clip can be easily attached to rail (1) either on the left or right
side of the arm.
2 Power switch
When the suspension system is on, the green indicator light in the
switch is lit.
3 Connector for control component (option)
Optional possibility of connecting a foot control panel or hand control
panel. (In the standard version, the connector is integrated in the wall
console).
4 Remote control socket
for triggering an AUX signal, e.g. to switch on/off an external device
operating at max. 24V/0.5A.
