G-30-1529-en OPMI® VISU 160 on S8, S81 & S88 Suspension Systems Issue 5.0
Printed on 09. 10. 2006
Operation 183
Failure of the zoom function
• Disconnect the surgical microscope from the suspension system. The
connector is located under the cover of the suspension arm. The illu-
mination remains on.
• Use zoom adjustment knob (1) of the microscope to manually set the
magnification required (if necessary, use a tool, e.g. a screwdriver,
coin, etc.)
1
