Zeiss S8 - Table of Contents

G-30-1529-en OPMI® VISU 160 on S8, S81 & S88 Suspension Systems Issue 5.0
Printed on 09. 10. 2006
3
Contents
– Key to symbols 2
Functions at a glance 7
– VISU 160 surgical microscope 8
– Illumination systems 9
– S88 floor stand 12
– S8 ceiling mount 14
– S81 ceiling mount 16
Safety 19
– Notes on installation and use 21
– When using a wide-angle observation system (e.g. BIOM 3) 27
– Phototoxic retinal injury in eye surgery 27
– Safety devices of the suspension systems 32
– Warning labels and notes 42
Description 49
VISU 160 surgical microscope 52
– Intended use 52
– Description of the modules 52
– Illumination system 57
– Controls, displays, connections 60
– Binocular tubes and eyepieces 66
Illumination systems 72
– Halogen illumination system 74
– Superlux Eye illumination system 78
– Superlux Eye illumination system with additional integrated
halogen illumination (option) 82
Identical modules of the suspension systems 88
– Suspension arm 88
– Display field with control keys 90
S88 floor stand 92
