126 Preparations
G-30-1529-en OPMI® VISU 160 on S8, S81 & S88 Suspension Systems Issue 5.0
Printed on 09. 10. 2006
• Screw in securing screw (7) and tighten it firmly. Securing screw (7)
must go into groove (9). This is ensured when the securing screw is
flush with the outer surface.
• Hook coupling (12) with the attached surgical microscope from above
into receptacle (11) on the suspension arm, and tilt the coupling
downward into its vertical position.
• Tighten mounting screw (3) firmly using a hex key.
• Insert cable clip (10) into opening (13) of the coupling.
• Make the electrical connections as required.
• Perform the balance setting procedure.
Warning!
Before using and after re-equipping the unit, always make sure that se-
curing screws (3), (4) and (7) have been tightened firmly.
Note:
The procedures for mounting the coupling need not be performed on sur-
gical microscopes equipped with an integrated coupling.
