160 Operation
G-30-1529-en OPMI® VISU 160 on S8, S81 & S88 Suspension Systems Issue 5.0
Printed on 09. 10. 2006
Basic mode
The basic mode is always displayed in the normal operating status.
In the basic mode, the following settings are displayed, depending on the
installed surgical microscope:
Setting the user ID (USER)
Every time you switch on the system, the basic mode is automatically dis-
played.
In the basic mode, the lower display field generally shows the current
USER, i.e. the user ID selected when the system was last switched off is
displayed. When the system is switched on, all settings for this user will
be activated, Exception: the lamp brightness, which is always set to the
minimum value.
User data records can be stored for a maximum of 9 different users.
Keys "∇" and "∆" assigned to the lower display field permit you to select
a user ID between 1 and 9.
Saving parameter settings
As soon as you have entered a parameter setting, it is saved under the
current user ID.
Note:
If possible, each user should be assigned his own user ID under which he
can enter and save his specific parameter settings. This permits each
user to call up his specific set of parameters via his user ID and to work
with these settings.
Caution:
Make sure never to change the settings of another user. It is therefore ad-
visable that you only use your own user ID for your work. Remember that
all settings made are stored under the user ID currently selected.
Note:
In the Superlux Eye illumination system with additional, integrated hal-
ogen illumination (option), the lamps are numbered as follows:
In the upper display field the current lamp brightness
In the middle display
field
Halogen: backup lamp
Xenon: Xe
Xenon with additional integrated halogen il-
lumination (option): halogen
In the lower display field the user ID
MODE
STORE MANUAL
USER
1
1
1.5
Basic mode
Halogen
MODE
STORE MANUAL
USER
1
1
1.5
2
1.5
Xe
Xenon
Xenon with hal-
ogen (option)
MODE
STORE MANUAL
USER
1
1
1.5
2
1.5
