G-30-1529-en OPMI® VISU 160 on S8, S81 & S88 Suspension Systems Issue 5.0
Printed on 09. 10. 2006
Operation 163
Control functions for the OPMI
The control functions for the OPMI have been combined in 4 modes:
The various control functions are explained below.
"STORE" key
In the basic mode and speed mode, the current zoom setting of the sur-
gical microscope can be stored for the user currently selected.
The "STORE" key has no function in the configuration modes.
The current zoom value is saved as zoom memory (ZOOM-MEM).
You can set the instrument to this stored zoom value by pressing key C
or D on the foot control panel if the XYZ-RES function has been assigned
to one of these keys in configuration mode 1. You can also set the stored
zoom value using the RESET key on the X-Y coupling.
Caution:
Be extremely careful when changing these settings. You should change
settings only under your own user ID. Notify all users of any changes, or
make sure that each user only works under his own user ID.
Basic mode
– Setting the lamp brightness
– Setting the user ID
Speed mode
– Setting the speed for focusing
– Setting the speed for the zoom
function
– Setting the speed for the X-Y
coupling
Configuration mode 1
– Assigning a function to button
C of the foot control panel
– Assigning a function to button
D of the foot control panel
– Setting the focus speed de-
pending on the zoom setting
Configuration mode 2
– Setting the magnetic brakes to
be released by activating the
release button in the handgrip.
