G-30-1529-en OPMI® VISU 160 on S8, S81 & S88 Suspension Systems Issue 5.0
Printed on 09. 10. 2006
Technical data 213
Mechanical data
Swing-in stops Patented retinal protection device
Pat. No. DE 33 39 17 2 C2
Patented field stop for reduced glare from the
sclera
Pat. No. G 91 03 43 3.7
Horizontal slit, 2.5 mm wide, continuously mov-
able in the vertical direction in the field of view
Horizontal slit, 5 mm wide, continuously movable
in the vertical direction in the field of view
Vertical slit, 2.5 mm wide, snaps in at the center
of the field of view
Front-to-back tilt of
microscope
With self-locking gear drive, manually adjustable
using a knob.
Tilt angle ± 180°
X-Y coupling Adjustment range: max. 40 mm x 40 mm
Automatic centering at the press of a button
Weight approx. 8.2 kg (without tube, objective lens and
eyepieces)
