G-30-1529-en OPMI® VISU 160 on S8, S81 & S88 Suspension Systems Issue 5.0
Printed on 09. 10. 2006
5
Connections 132
– Connecting the surgical microscope 132
– Connecting the S light guide 132
– Strain relief device on S88 floor stand 134
– Connecting the S88 floor stand 136
– Relocating the system 138
Adjusting the supension system 140
– Adjusting the balance setting of the suspension arm 140
– Adjusting the limit of downward movement 142
– Positioning the S8 ceiling mount 144
Settings on the control and display panel 146
– Adjusting the suspension system 146
Adjusting the surgical microscope 147
– Adjusting the tilt angle 148
– Adjusting the microscope tilt to angles greater than 15° 149
Operation 151
Checklist 152
– When using a wide-angle observation system (e.g. BIOM 3) 155
Positioning the S88 floor stand 156
Using the display and key field 158
– General functions 158
– Operating the OPMI® on the suspension system 162
Procedure 174
What to do in an emergency 176
– Failure of the halogen lamp 176
– Lamp failure in Superlux Eye illumination system 178
– Failure of lamp control 180
– Failure of focusing system 180
– Failure of magnetic brakes 182
– Failure of the X-Y coupling 182
– Failure of the zoom function 183
Maintenance / Further information 185
– Trouble-shooting 186
