62 Description
G-30-1529-en OPMI® VISU 160 on S8, S81 & S88 Suspension Systems Issue 5.0
Printed on 09. 10. 2006
8 Dust cover
9 Handgrips with turning function for the release of the magnetic brakes
of the suspension system (function only available on suspension sys-
tems with magnetic brakes)
For as long as you turn the left and/or right handgrip to the left or right
and keep them in their turned position (turning function), the magnetic
brakes of the suspension system are released.
10 Display of the zoom system's magnification factor
11 Securing screw
– Handgrip turned and held in
turned position Magnetic brakes are unlocked, the
instrument can be moved as re-
quired.
– Handgrip not turned Magnetic brakes are locked, the
instrument cannot be moved.
