Invertertube (option)
The tiltable tube has an inverter function and has been designed for oph-
thalmic use. Many wide-angle observation systems for the posterior seg-
ment of the eye provide an inverted intermediate image which is viewed
through the microscope. The inverter is used to erect an inverted image.
When activating the wide-angle observation system, you must also acti-
vate the inverter of the tiltable tube. When swinging out the wide-angle ob-
servation system, you must also deactivate the inverter of the tiltable tube
again.
With the inverter deactivated, the tiltable tube has the same optical func-
tion as a normal tiltable tube.
To ensure sterility, the controls can be equipped with sterilizable caps.
1 Invertertube - 110° tiltable binocular tube
2 Eyepiece mount
3 Knob for setting the interpupillary distance (54 mm to 76 mm)
The correct position has been reached when the two eyepiece images
merge into one.
4 Inverter selection knob
The inverter can be turned about 360° and snaps in at the two defined
positions.
5 Symbol for
deactivated inverter on the inverter selection knob
6 Symbol for activated inverter on the inverter selection knob
7 Tilt axis
-10° to +100°
8 Cat. No.
If you have any questions for our service staff, please always specify
the relevant Cat. No.
