70 Description
G-30-1529-en OPMI® VISU 160 on S8, S81 & S88 Suspension Systems Issue 5.0
Printed on 09. 10. 2006
Widefield eyepieces with magnetic coupling
Note:
When you remove these eyepieces from the tube, please note that they
are fitted with a magnetic coupling. When mounted, the eyepieces display
a very weak magnetic field, so that the usual rules for the handling of mag-
nets must only be observed with eyepieces which have not been mounted
on the microscope:
• Do not place the eyepieces close to instruments where there is any
risk of magnetization.
• Do not place the eyepieces on sensitive electronic units such as infu-
sion pumps, cardiac pace-makers, measuring instruments or magnet-
ic data carriers such as disks, audiotapes and videotapes, or credit
cards.
• Always store eyepieces not used in their original packaging.
1 Eyecup
Always adjust the eyecups in such a way that you can see the full field
of view.
2 Diopter adjustment ring
The eyepieces provide ametropia compensation between -8 D and
+5 D. Eyeglass wearers who perform surgery wearing their glasses
set the diopter adjustment ring to 0 D. Turn the ring until you have ob-
tained the optimum setting. An integrated brake holds the ring in the
position set.
3 Diopter scale
for reading the prescription set.
– Viewing with eyeglasses: Screw in the eyecups all the way.
– Viewing without eyeglasses: Screw out the eyecups until you
see the full field of view.
