84 Description
G-30-1529-en OPMI® VISU 160 on S8, S81 & S88 Suspension Systems Issue 5.0
Printed on 09. 10. 2006
4 Flap
The flap is the mechanical indicator for the operating status of the hal-
ogen lamps.
– When the flap is closed, the main lamp is operative (green light
(13) is on).
– When the flap is open, the main lamp has failed. The backup lamp
is operative (yellow light (12) is on).
5 Filter selector knobs for additional integrated halogen illumination
The filter knobs have four positions:
6 Opening the lamp module of additional integrated halogen illumination
When you press this button, the lamp module is slightly ejected. Pull
out the lamp module all the way for lamp change.
7 Manual activation of the halogen backup lamp
If the automatic activation system fails, press this button to switch on
the backup lamp.
8 Indicator: Superlux Eye backup lamp is in use
When the red segment in the knob lights up, the backup lamp is in use.
9 Ventilation grid for additional integrated halogen illumination
Do not cover the ventilation grid! For example, drapes could be cov-
ering the grid. This can lead to overheating of the lamp modules and
to lamp failure.
10 Lamp module of additional integrated halogen illumination
11 Superlux Eye lamp module
0 no filter
1 GG 475 filter : to protect the patient's eye during surgery against
unnecessary (blue) radiation (retinal injury).
2 KK 40 filter: to increase color temperature
3 no filter
