G-30-1529-en OPMI® VISU 160 on S8, S81 & S88 Suspension Systems Issue 5.0
Printed on 09. 10. 2006
Description 91
Keys
Three keys and an LED are provided below the displays.
Use the "MODE", "STORE" and "MANUAL" keys to select the different
control functions (modes).
"MODE" key and "STORE" key
The "MODE" and "STORE" keys permit you to access the different modes
of the user interface. For details, please see the chapter "Operation".
"STORE" key
You use the "STORE" key, for example, to save the current focus and
zoom settings for OPMI
®
Vario on the suspension system.
"MANUAL" key
The "MANUAL" key permits you to switch to manual operation. For de-
tails, please see the chapter "Operation".
Yellow LED above the "MANUAL" key
The yellow LED is lit when you have switched to the manual mode.
The illustration shows the control and display panel of the suspension
system with two halogen illumination systems (option).
