9. Technical Specications
PV Input
PV Input Ports
PV Input Rated Voltage
PV Input Recommended Power
Number of MPPTs 2
MPPT1 Connections PV1 & PV2
MPPT2 Connections PV3 & PV4
Each MPPT Rated Voltage Range
Each MPPT Rated Current 20.5A
Each MPPT Rated Power 900W
Dual MPPTs Rated Power 1800W
AC Power Input/Output
Rated Power 1200W
Rated Voltage 220V/230V/240V
Rated Frequency 50Hz
Rated Current 5.5A
Battery Terminal
Charging Mode
Maximum Input Power
One AB1000 Battery: 950W
One AB2000 Battery: 1200W
Two or More Batteries: 1600W
Discharging Mode
Maximum Output Power 1200W
Environmental Adaptability
Charging Temperature
Discharging Temperature
Storage Temperature
Maximum Relative Humidity 90%
IP Rating IP65
Others
Wireless Type Bluetooth, Wi-Fi
OTA Updates Supported
Dimensions 350 x 202 x 78mm
Product Weight
