• Typical Application Examples
• Detailed Explanation and Instructions
• Assistance for Calculation, Configuration and Wiring
Date: 03/2006
ZENITH PUMPS
ZeDrive DC Motor Drive
User Manual
Setup System Easily
Zenith
®
Pumps
SET
SPEED
TACH
7
4
1
--
8
5
2
0
9
6
3
.
CLEAR ENTER
Run
Jog
Preset
Limit Alarm
Dev Alarm
CONTROL PARAMETERS MONITOR VARIABLES
CODE DESCRIPTION CODE DESCRIPTION CODE DESCRIPTION
1 PRI. SETPT 1 16 ACCEL RATE 40 TACH
2 PRI. SETPT 2 17 DECEL RATE 41 EXTERNAL REF.
3 SEC. SETPT 1 61 CTRL: PRI 42 AUX. INPUT
4 SEC. SETPT 2 62 CTRL: SEC 43 FEEDBACK
5 JOG SETPOINT 63 DISPLAY: PRI 44 DEVIATION
6 OUTPUT SETPT. 64 DISPLAY: SEC 45 SCALED REF.
10 MIN. LIMIT 65 GAIN 46 RAMPED REF.
11 MAX. LIMIT 66 RESET 47 OUTPUT
12 LOW ALARM 67 RATE 48 TRIM OUTPUT
13 HIGH ALARM 68 TRIM ATHOR 50 ACTIVE MODE
14 LOW ALARM 69 RATE THRSLD 51 ENTRY ERRORS
15 HIGH ALARM 74 0 SPD LGC 52 ALARM STATUS
ZeDrive
