ZeDrive Standard Specification
Voltage Class Unit 115 VAC Class 230 VAC Class
Rated Input Voltage
VAC 115 (104 ~ 132), 1 Phase 230 (207 ~ 264), 1 Phase
Rated Input Frequency
Hz 60/50
Horse Power Rating
HP 1/4 ~ 1 1/2 ~ 2
Rated Output Current
A 4 ~ 16 (Default: 15 Amp)
Rated Output Voltage
VDC 0 ~ 90 Armature (100V Field) 0 ~ 180 Armature (200V Field)
Operating Temperature
˚C 0˚C ~ 55˚C
Relative Humidity
0% ~ 90%, Non-condensing
Cooling
Natural, air cooled
NEMA Ratings
Standalone: NEMA 4, Enclosure: NEMA 12
Classifications:
UL
Closed Loop Accuracy
Master Format: 0.01% Set Speed; Follower Format: Zero accumulative error
Tuning
Gain, Reset and Rate
Scaling Format
Master, Follower, Offset, Direct
Keypad Controls
Set Speed, Tach Display, Numeric Keys, Up/Down Buttons
Serial Communication
RS-422, Full parameter access & control
Protection
1 Amp internal fuse for control protection,
15 Amp internal fuse for armature protection
Analog Inputs
0 ~ 10 VDC, or, 4 ~ 20 mA
Analog Outputs
VDC 0 ~ 10 VDC, or, 4 ~ 20 mA
Setpoints
6 Setpoints (4 Master/Follower, 1 Direct, 1 Jog)
Control Inputs
Run, R-Stop, F-Stop, Jog, Closed/ Open-Loop,
Primary/Secondary Mode, Primary Setpoint Select,
Secondary Setpoint Select,
Ramp Disable, Keypad Lockout, Local/Computer
Frequency Input
Zero Crossing(Magnetic Pickup),
0 ~ 10KHz for Feedback, External Reference, and Offset,
or
Open-collector (Encoder/Proximity),
0~30KHz for Feedback & External Reference,
0 ~ 10KHz for Offset
Status Outputs
Hi Alarm, Lo Alarm
Ramped Error, Scaled Error
Zero Speed
