Set and Display as Pump RPM

1. Preliminary Action:

• Reducer Gear Ratio — R. If the pump is directly coupled with the motor, the gear ratio R=1

• Motor maximum speed — V

(RPM)

2. Calculation:

None

3. Coding:

Check and change the following codes

Code 10 = 0

Code 11 = V

Code 20 = V

/ R

Code 22 = V

/ R

Code 34 = V

Code 37 = V

4. Wiring:

No wiring changes for this application

5. Result:

• The units of the setpoint and Tach on the drive’s panel will be in Pump’s RPM
