Page 46
TO GET ASSISTANCE, CALL: 919-774-7667
ZENITH PUMPS
11
Maximum Limit
Default:
1800
Units:
Motor RPM
Range:
0~9999
12
Low Alarm
Default:
0
Units:
Motor RPM
Range:
0~9999
13
Hi
h Alarm
Default:
1800
Units:
Motor RPM
Range:
0~9999
14
Ramped Error Alarm
Default:
1800
Units:
Motor RPM
Range:
0~9999
15
Scaled Error Alarm
Default:
1800
Units:
Motor RPM
Range:
0~9999
This parameter establishes the error band (defined as
Final Speed minus actual speed) at which DEV ALARM
output is turned on. If the difference between actual
speed and final desired speed is greater than or equal to
C15, the alarm is turned on.
This parameter establishes the maximum level of motor
RPM during operation. It is allowable to program a
setpoint which is above this value, however the
controller will enforce this maximum speed (measured
at the motor shaft), except when attempting to recover
position error.
This parameter establishes the level of motor RPM
during operation below which the LO-ALARM output is
turned on.
This parameter establishes the level of motor RPM
during operation above which the HI-ALARM output is
turned on.
This parameter establishes the error band (defined as
Ramped Speed minus actual speed) at which DEV-
ALARM output is turned on. If the difference between
actual speed and ramped desired speed is greater than
or equal to C14, the alarm is turned on.
