TO GET ASSISTANCE, CALL: 919-774-7667
ZENITH PUMPS
33
Max RPM External Reference - Primary
Default:
1800
Units:
PPR (Number of Pulses Per Revolution)
Range:
0~3270
34
Max RPM Feedback - Primary
Default:
1800
Units:
PPR (Number of Pulses Per Revolution)
Range:
0~3270
35
Max RPM Aux / Offset - Primary
Default:
1800
Units:
PPR (Number of Pulses Per Revolution)
Range:
0~3270
36
Max RPM External Reference - Secondary
Default:
1800
Units:
PPR (Number of Pulses Per Revolution)
Range:
0~3270
37
Max RPM Feedback - Secondary
Default:
1800
Units:
PPR (Number of Pulses Per Revolution)
Range:
0~3270
38
Max RPM Aux / Offset - Secondary
Default:
1800
Units:
PPR (Number of Pulses Per Revolution)
Range:
0~3270
It sets the full-scale speed of the device driving External
Reference, and is used in Follower or Offset formats
when the primary data set is selected.
It sets the full-scale speed of the motor. When the motor
is turning at this speed with a primary setpoint selected,
the controlled process will be at C20 (Primary Setpoint
Maximum).
It sets the full-scale speed of the device driving the
Auxiliary / Offset frequency input, and is used in the
Offset format when the primary data set is selected.
It sets the full-scale speed of the device driving External
Reference, and is used in Follower or Offset formats
when the secondary data set is selected.
It sets the full-scale speed of the motor. When the motor
is turning at this speed with a secondary setpoint
selected, the controlled process will be at C21
(Secondary Setpoint Maximum).
It sets the full-scale speed of the device driving the
Auxiliary / Offset frequency input, and is used in the
Offset format when the secondary data set is selected.
