TO GET ASSISTANCE, CALL: 919-774-7667
ZENITH PUMPS
2 HP TEFC MOTOR
1 HP TEFC MOTOR
1 & 2 HP WASH DOWN MOTORS
PERMANENT MAGNET MOTORS
MOTOR ARMATURE AND FIELD WIRING - CUSTOMER'S RESPONSIBILITY
TO TB1-5
TO TB1-4
1/2 HP EXPLOSION PROOF MOTOR
1/4 & 1/2 HP TENV & SEALED
TIGHT (WASH DOWN) MOTORS
CONNECT
TO TB1-3
CONNECT
TO TB1-5
CONNECT
TO TB1-4
TO TB1-4
MOTOR END
W/ COVER
REMOVED
TO TB1-5
CASE GROUND
TO TB1-3
TO TB1-4
FIELD WOUND MOTORS
TO TB1-5
1 & 2 HP EXPLOSION PROOF MOTORS
TO TB1-4
TO TB1-5
NOTES:
1. THE MOTOR CONNECTIONS SHOWN WILL PRODUCE A COUNTER-
CLOCKWISE ROTATION OF THE REDUCER OUTPUT SHAFT, VIEWED FROM THE
PUMP END (AS OPPOSED TO THE MOTOR END). THIS ROTATION SHOULD BE
CORRECT FOR MOST APPLICATIONS. IF ROTATION IS INCORRECT, REVERSE
THE A1 AND A2 CONNECTIONS.
2. IF THE MOTOR IN USE HAS A THERMOSTAT, IT MAY BE CONNECTED TO TB2-5
AND TB2-6, AFTER REMOVING THE JUMPER.
