Overview
Link Configuration
Overview
The Model 6301 has a single link (channel) labeled Link 1. The Model 6302 has two
links (channels) labeled Link 1 and Link 2. The parameters specific to each link are
described below. When two Links are configured to interoperate together, they are
considered “paired.”
Parameter Purpose
Link Name/ID The field customized alternate name for this link.
1-20 characters. Spaces are not allowed.
IP Protocol Determines the protocol used for VoIP communication.
Zetron (default)
Peer IP Connection
SIP Receive Port
Number
The port number used to receive Session Initiation Protocol (SIP) messages, which
control Push-to-Talk (PTT) among other things. This should match the SIP
Receive Port Number of the paired link.
Valid range 0-65535. Default 5060.
RTP Receive Port
Number
This is the IP port number used to receive Real Time Protocol (RTP) which
conveys Voice-over-IP. This should match the RTP Receive Port Number of the
paired link. The RTP port number must be even because the companion RTCP
service uses the next/odd numbered port.
Valid range 0-65535. Default 4000.
39
