Specifications
The following figure provides two simple examples of the Model 6300 used to connect
legacy radio equipment and intercoms across an IP network.
Figure 1 – Model 6300 example configurations
IP Network
LAN
Local Control
Radios
Operator Control
Equipment
Model 6300
IP Gateway
Model 6300
IP Gateway
IP Network
LAN
Intercom
(Hoot ‘n Holler /
Squawk Box)
Model 6300
IP Gateway
Model 6300
IP Gateway
Intercom
(Hoot ‘n Holler /
Squawk Box)
Specifications
Physical Dimensions
Rack-mounted
IP Gateways are preferably mounted to a 19-inch rack-mount plate located on a rack in a
controlled server environment. Each plate mounts up to two IP Gateways.
Figure 2 – Rack-mounted IP Gateways
Network Power
Model 6300 IP Gateway
Status IP Radio
TX
RX
Link 1
Status
TX
RX
Link 2
IP Radio
Network Power
Model 6300 IP Gateway
Status IP Radio
TX
RX
Link 1
Status
TX
RX
Link 2
IP Radio
Parameter Description
Height: 1.75 inches / 1 rack units
Width: 19 inches
Depth: 10 inches
