Overview
43
Valid range 0 to 2000 milliseconds. Default 100.
I/O Control
I/O Direction This parameter is only available if IP Protocol is set to Zetron.
Input (default) or Output.
Input Polarity This parameter is only available if IP Protocol is set to Zetron and if I/O
Direction is set to Input.
Determines if the input is considered active while low or high. Active Low is the
default.
Output Polarity This parameter is only available if IP Protocol is set to Zetron and if I/O
Direction is set to Output.
Determines if the output is considered active while low or high. Active Low is the
default.
Output Control This parameter is only available if IP Protocol is set to Zetron and if I/O
Direction is set to Output.
Determines if the Output Control is Disabled or Remote Input (default).
Serial Data
Serial Data Enable This parameter is only available if IP Protocol is set to Zetron.
Enables or disables the serial port.
Serial Port Baud Rate
Serial Port Data Bits
Serial Port Parity
Serial Port Stop Bits
This parameter is only available if IP Protocol is set to Zetron and if Enable
Serial Port is checked (enabled). Valid baud rates are 300, 1200, 2400, 4800,
9600, 19200, and 38400.
The parameters define the serial port communication settings.
The defaults are 9600, 8, None, 1.
