SmartLPR
®
Access User Manual Installation
Quercus Technologies 30
Unscrew the main body of the connector.
Pass the cables through the cable glands and through the
main body of the connector.
Connect the cables to their pin (rear view)
5
Tighten the main body of the connector.
Tighten the cable glands at the bottom of the connector.
Steps for assembling the AC power cable:
Remove the cable gland from the main body of the
connector.
Unscrew the main body of the connector.
2
1
Pin
Meaning
1
+12V
2
GND
