ZKTeco SpeedFace-V5L User Manual

2.8-inch Linux Visible Light Product User Manual 23
Item
Description
Enable Domain Name
When this function is enabled, the domain name mode “http://...” will be used,
such as http://www.XYZ.com, while “XYZ” denotes the domain name when this
mode is turned ON.
Server Address
IP address of the ADMS server.
Server Port
Port used by the ADMS server.
Enable Proxy Server
When you choose to enable the proxy, you need to set the IP address and port
number of the proxy server.

ZKTeco SpeedFace-V5L Specifications

General

Face capacity	6000
Housing color	Black, Grey
Event capacity	200000
Built-in processor	Yes
Face recognition duration	1 s
Operating temperature (T-T)	-10 - 45 °C
Temperature measurement range	34 - 45 °C
Temperature measurement accuracy	0.3 °C
Temperature measurement distance	30 - 50 cm
Operating relative humidity (H-H)	10 - 90 %
Input current	3 A
Input voltage	12 V
Ethernet LAN (RJ-45) ports	1
Screen shape	Flat
Display diagonal	5 \
Display technology	TFT
Sensor type	CMOS
Camera resolution (numeric)	2 MP
Type	Face recognition terminal

Weight and Dimensions

Depth (with stand)	22.5 mm
Width (with stand)	91.9 mm
Height (with stand)	220 mm
