ZKTeco SpeedFace-V5L User Manual

20 2.8-inch Linux Visible Light Product User Manual
Item
Descriptions
IP Address
The factory default value is 192.168.1.201. Please adjust them according to the
actual network situation.
Subnet Mask
The factory default value is 255.255.255.0. Please adjust them according to the
actual network situation.
DNS
The factory default address is 0.0.0.0. Please adjust them according to the actual
network situation.
TCP COMM. Port
The factory default value is 4370. Please adjust them according to the actual
network situation.
DHCP
Dynamic Host Configuration Protocol, which is to dynamically allocate IP
addresses for clients via server.
Display in Status Bar
To set whether to display the network icon on the status bar.
5.2 PC Connection
To improve the security of data, please set a Comm Key for communication between the device and the PC.
If a Comm Key is set, this connection password must be entered before the device can be connected to the PC
software.
Select PC Connection on the Comm. Settings interface.
Item
Descriptions
Comm Key
The default password is 0, which can changed. The Comm Key may contain1-6 digits.
Device ID
Identity number of the device, which ranges between 1 and 254. If the
communication method is RS232/RS485, you need to input this device ID in the
software communication interface.

ZKTeco SpeedFace-V5L Specifications

General

Face capacity	6000
Housing color	Black, Grey
Event capacity	200000
Built-in processor	Yes
Face recognition duration	1 s
Operating temperature (T-T)	-10 - 45 °C
Temperature measurement range	34 - 45 °C
Temperature measurement accuracy	0.3 °C
Temperature measurement distance	30 - 50 cm
Operating relative humidity (H-H)	10 - 90 %
Input current	3 A
Input voltage	12 V
Ethernet LAN (RJ-45) ports	1
Screen shape	Flat
Display diagonal	5 \
Display technology	TFT
Sensor type	CMOS
Camera resolution (numeric)	2 MP
Type	Face recognition terminal

Weight and Dimensions

Depth (with stand)	22.5 mm
Width (with stand)	91.9 mm
Height (with stand)	220 mm
