Zodiac VORTEX-PRO VX40 - Connecting the Control Box to Caddy (VX50 4 WD; VX55 4 WD) or Base (VX40); Connecting Floating Cable to Control Box

Figure 12. Attach Control box to Base
3.4 Connecting Floating Cable to Control
Box
WARNING
Failuretocomplywiththefollowingwarningscan
resultinpermanentinjury,electrocutionordrowning.
PREVENT ELECTRICAL SHOCK
• Keepthecontrolboxatleast3.5mfromtheedge
ofthepool.
• Thecleaneristobeinstalledinaccordancewith
therelevantrequirementsoftheAustralianwiring
rulesAS/NZS3000.Alsorefertotheinstallation
instructionsrelatingtotheswimmingpoolequipment
forwhichthecleanerwillbeanintegralpart.The
cleaneristobesuppliedthroughaResidualCurrent
Device(RCD)witharatedresidualoperatingcurrent
of30mA.
• Donotuseanextensioncordtoconnectthecontrol
box.
• Donotallowanyonetoswimwhilethecleanerisin
thepool.
• Thecontrolboxiswater-resistant,notwaterproof.
Inordertopreventelectrocution,neversubmerge
thecontrolboxorleaveexposedtoinclement
weather.
1. Unscrew the protective cap for the power cable
from the side of the control box by turning
counter-clockwise (Figure 12).
3.3 Connecting the Control box to Caddy
(VX50 4WD / VX55 4WD) or Base
(VX40)
VX50 4WD / VX55 4WD:
1. Align the bottom of the control box with the
notch at bottom of the control box hook on the
caddy (Figure 10).
Figure 10. Align Control box with Caddy Hook
2. Press control box onto the caddy hook until it
snaps and locks into position (Figure 11).
Figure 11. Attach the Control box onto Caddy
VX40:
1. Align the bottom of the control box with the
notch in the base (see Figure 12).
2. Presscontrolboxdownrmlytosnapinplace.
7
H0516700_REV A
