ZOLL R Series Manual

R SERIES — NON-INVASIVE BLOOD PRESSURE (NIBP) OPTION INSERT
16 www.zoll.com 9650-0914-01 Rev. C
Setting Alarms
The R Series NIBP option includes blood pressure alarms for the measurements shown in the
following table.
Before taking a measurement, ensure that all the NIBP alarms settings are appropriate for the
situation. See the R Series Operator’s Guide for instructions on setting alarms. When an NIBP
or heart rate alarm is triggered, the unit automatically initiates a single blood pressure
measurement. See the R Series Configuration Guide for instructions on how to enable/disable
this automatic measurement.
When the R Series unit is turned on, all alarm functions are disabled, and the alarm limits are
set to their default values for the selected patient type. Any changes to these settings remain in
effect until either the settings are changed for the patient type or for 10 seconds after the
R Series unit is turned off. You can configure the default alarm limits at power-up; see the
R Series Configuration Guide for more information.
Setting Alarm Limits
You can change all the alarm limits using standard R Series procedures. See the RSeries
Operator’s Guide for instructions on setting alarm limits.
Patient Type Alarm Parameter Default Setting Range (increments of 5)
Adult Systolic High 160 mmHg (21.3 kPa) 80-260 mmHg (10.7-34.7 kPa)
Low 90 mmHg (12.0 kPa) 40-140 mmHg (5.3-18.7 kPa)
Diastolic High 110mmHg (14.7kPa) 50-200 mmHg (6.7-26.7 kPa)
Low 50 mmHg (6.7 kPa) 25-100 mmHg (3.3-13.3 kPa)
Mean High 130 mmHg (17.3 kPa) 60-220 mmHg (8.0-29.3 kPa)
Low 60 mmHg (8.0 kPa) 30-120 mmHg (4.0-16.0 kPa)
Pediatric Systolic High 145 mmHg (19.3 kPa) 80-160 mmHg (10.7-21.3 kPa)
Low 75 mmHg (10.0 kPa) 35-140 mmHg (4.7-18.7 kPa)
Diastolic High 100 mmHg (13.3 kPa) 50-130 mmHg (6.7-17.3 kPa)
Low 35 mmHg (4.7 kPa) 20-100 mmHg (2.7-13.3 kPa)
Mean High 110mmHg (14.7kPa) 60-140 mmHg (8.0-18.7 kPa)
Low 50 mmHg (6.7 kPa) 30-120 mmHg (4.0-16.0 kPa)
Neonate Systolic High 100 mmHg (13.3 kPa) 60-130 mmHg (8.0-17.3 kPa)
Low 50 mmHg (6.7 kPa) 25-120 mmHg (3.3-16.0 kPa)
Diastolic High 70 mmHg (9.3 kPa) 30-105 mmHg (4.0-14.0 kPa)
Low 30 mmHg (4.0 kPa) 20-100 mmHg (2.7-13.3 kPa)
Mean High 80 mmHg (10.7 kPa) 35-110 mmHg (4.7-14.7 kPa)
Low 35 mmHg (4.7 kPa) 30-105 mmHg (4.0-14.0 kPa)

ZOLL R Series Specifications

General

Defibrillator Type	Manual and AED
Pacing	Yes
ECG Monitoring	Yes
SpO2 Monitoring	Yes
FAST-SpO2	Yes
IP Rating	IP55
Defibrillator Waveform	Biphasic
Energy Levels	1-360 Joules
Display	LCD
Pacer Type	Demand
Pacer Rate	30-180 ppm
Pacer Output	0 – 140 mA
EtCO2 Monitoring	Optional
NIBP Monitoring	Optional
Temperature Monitoring	Optional
Printer	Integrated
Battery Type	Lithium-ion
CPR Feedback	Yes
Data Storage	Internal memory
Connectivity	USB
