R SERIES — NON-INVASIVE BLOOD PRESSURE (NIBP) OPTION INSERT
26 www.zoll.com 9650-0914-01 Rev. C
Troubleshooting
The following table lists the error messages and problems associated with the NIBP option and
the associated corrective action(s). Read this section carefully. For further assistance, call
ZOLL Technical Service at 1-800-348-9011. International customers should call the nearest
authorized ZOLL Medical Corporation representative.
Message/Symptom Problem User Action
--- (dashed lines in
NIBP field)
No NIBP measurement has been taken.
The last measurement taken has expired
after 120 minutes.
The patient type has been changed.
None, normal operation.
Repeat NIBP measurement.
CALIBRATE NIBP NIBP calibration is incomplete or failed Recalibrate NIBP. (See the R Series
Service Manual for details).
NIBP COMM ERROR There is a communication problem with the
NIBP module.
Cycle power and retry.
If problem persists, return for service.
NIBP FAULT No communication from the NIBP module.
NIBP module failed self-test.
Cycle power, and retry.
If the problem persists, return for
service.
NIBP MEAS
ABORTED
Cuff inflation pressure is set too high for
attached cuff.
Inflation is too fast.
R Series is unable to find systolic value for
180 seconds.
Defibrillator is charged or charging. User
initiated abort.
Verify that you are using proper size
cuff.
Check for cuff and hose blockages.
Confirm that the unit was not charging.
If the problem persists, return for
service.
NIBP NOT READY The defibrillator is charged or charging in
progress.
NIBP module is performing power-up
self-test.
Wait until the unit discharges before
taking the next measurement.
Wait for more than 10 seconds after
power-up before taking blood pressure
measurements.
NIBP OUT OF RANGE The data from the NIBP module is out of
range.
Measure patient’s blood pressure with
other equipment.
Check cuff fit and positioning.
Switch cuff to other arm.
If problem persists, return for service.
REPEAT NIBP MEAS The unit exceeded the maximum number of
inflation attempts.
The unit exceeded the 180-second
measurement time limit.
Check cuff and hose.
Repeat NIBP measurement.
To Next Page
