Preparing to Take Measurements
9650-0914-01 Rev. C R Series Non-Invasive Blood Pressure (NIBP) 9
Select the appropriate size cuff for the patient from the following table:
Caution You must use the 3 m hose when making neonatal NIBP measurements with the R Series. The 3 m
hose (ZOLL Part No. 8000-0662) is standard on R Series units. Do not use the 1.5 m hose when
making neonatal NIBP measurements; the cuff may not inflate, causing the unit to abort the NIBP
measurement.
You can order additional cuffs and hoses from ZOLL Medical Corporation. See “NIBP
Accessories” on page 24.
Connecting the Hose
The NIBP option comes with a hose that has a plastic connector on one end and a metal
connector on the other end; you must attach the hose to both the R Series unit rear panel using
the metal connector and the cuff’s hose using the plastic connector. The cuff has its own short
length of hose with a connector on the end. This connector fits into the end of the hose that is
not connected to the R Series unit.
To connect the hose:
Limb Circumference Cuff
38 to 50 cm
(14.96 to 19.69 in.)
Thigh
31 to 40 cm
(12.20 to 15.75 in.)
Large Adult
23 to 33 cm
(9.06 to 12.99 in.)
Adult
17 to 25 cm
(6.69 to 9.84 in.)
Small Adult
12 to 19 cm
(4.72 to 7.48 in.)
Child
8.0 cm to 15.0 cm
(3.1 to 5.9 in.)
Neonate #5
7.0 to 13.0 cm
(2.8 to 5.1 in.)
Neonate #4
6.0 to 11.0 cm
(2.4 to 4.3 in.)
Neonate #3
4.0 to 8.0 cm
(1.6 to 3.1 in.)
Neonate #2
3.0 to 6.0 cm
(1.2 to 2.4 in.)
Neonate #1
