Table 29. WMM Menu Option
Option Description
WMM Support Select On to include the WME Information Element in beacon frame.
No-Acknowledgement Select On to not transmit acknowledgments for data.
Power Save Support
Select On to allow the AP (cable modem/router) queuing packets for
stations/clients in power-save mode. Queued packets are transmitted
when the station/client notifies AP that it has left power-save mode.
EDCA AP Parameters
Enter the transmit parameters for traffic transmitted from the AP to
the STA (station) for the four Access Categories (AC): Best Effort
(AC_BE), Background (AC_BK), Video (AC_VI) and Voice (AC_VO).
Transmit parameters include Contention Window (CWmin and
CWmax), Arbitration Inter Frame Spacing Number (AIFSN), and
Transmit Opportunity Limit (TXOP Limit).
There are also two AP-specific settings:
y Admission Control: Specify if admission control is enforced for
the Access Categories.
y Discard Oldest First. Specify the discard policy for the queues. On
discards the oldest first and Off discards the newest first.
EDCA STA Parameters
Specifies the transmit parameters for traffic transmitted from the STA
(station) to the AP for the four Access Categories (AC): Best Effort
(AC_BE), Background (AC_BK), Video (AC_VI), and Voice (AC_VO).
Transmit parameters include Contention Window (CWmin and
CWmax), Arbitration Inter Frame Spacing Number (AIFSN) and
Transmit Opportunity Limit (TXOP Limit).
Bridging
The Bridging page allows you to configure WDS (Wireless Distribution System) feature.
Only those bridges listed in the Remote Bridges table will be granted access. APs must operate in
the same channel to be bridged together.
To access the Bridging page:
1 Click Wireless in the menu bar.
2 Then click the Bridging submenu.
Figure 40 shows an example of the menu and Table 30 describes the items you can select.
