14
RESET: Press and hold this button at least 10
seconds in the unlikely event that you want to
restore the default factory settings.
WLAN
Press and hold this button for 5 seconds to turn your
wireless connection on or off.
LAN 1-4
(Gigabit Ethernet 1-4)
Four 10/100/1000 auto-sensing Ethernet ports for
computers and other devices that have an Ethernet
port.
Cable
Connect your coaxial cable line to this port.
Front Panel LEDs
Your Zoom cable modem has several lights on its front panel to help you monitor
the Cable Modem/Router’s status.
LIGHT COLOR DESCRIPTION
Power
Green
ON:
Power is supplied to the cable
modem/router
OFF:
Power is not supplied to the cable
modem/router
DOWNSTREAM
Downstream
sync
Green or
Blue
Green Blinking:
Scanning for DS channel
Green ON:
Synchronized on 1 channel
only
Blue Blinking:
Negotiating bonded
channel(s)*
Blue ON:
Bonded with 2 or more
channels
UPSTREAM
Upstream sync
Green or
Blue
Green Blinking:
Ranging is in progress
Green ON:
Ranging is complete; operate
on 1 channel
Blue Blinking:
Negotiating bonded
channel(s)*
Blue ON:
Bonded with 2 or more
channels
OFF:
Upstream channel is inactive
Online
Green
Blinking:
Cable interface is acquiring IP, Time
of Day, and configuration
ON:
Cable modem/router is online
OFF:
Cable modem/router is offline
